PhotoMovie （https://github.com/yellowcath/PhotoMovie） 可輕松實現類似抖音、微視、美拍的照片電影功能。
效果如下
濾鏡效果
轉場效果
使用
首先在項目根目錄的build.gradle文件里添加maven庫
allprojects { repositories { ... maven { url 'https://www.jitpack.io' } } }再在需要用的Module的build.gradle里添加依賴
dependencies { compile 'com.github.yellowcath:PhotoMovie:1.5.0'}基本用法
可參照 DemoPresenter
//添加圖片 List<PhotoData> photoDataList = new LinkedList<PhotoData>(); photoDataList.add(new SimplePhotoData(context,photoPath1,PhotoData.STATE_LOCAL)); ... photoDataList.add(new SimplePhotoData(context,photoPathN,PhotoData.STATE_LOCAL)); //生成圖片源 PhotoSource photoSource = new PhotoSource(photoDataList); //生成照片電影(使用預定義的水平轉場動畫) PhotoMovie photoMovie = PhotoMovieFactory.generatePhotoMovie(photoSource, PhotoMovieFactory.PhotoMovieType.HORIZONTAL_TRANS); //生成負責繪制電影內容的MovieRenderer MovieRenderer movieRenderer = new GLTextureMovieRender(glTextureView); /** * OR MovieRenderer movieRenderer = new GLSurfaceMovieRenderer(glSurfaceView); */ //照片電影播放器 PhotoMoviePlayer photoMoviePlayer = new PhotoMoviePlayer(context); photoMoviePlayer.setMovieRenderer(mMovieRenderer); photoMoviePlayer.setMovieListener(...); photoMoviePlayer.setLoop(true); photoMoviePlayer.setOnPreparedListener(new PhotoMoviePlayer.OnPreparedListener() { @Override public void onPreparing(PhotoMoviePlayer moviePlayer, float progress) { } @Override public void onPrepared(PhotoMoviePlayer moviePlayer, int prepared, int total) { mPhotoMoviePlayer.start(); } @Override public void onError(PhotoMoviePlayer moviePlayer) { } }); photoMoviePlayer.prepare();輕松擴展
PhotoMovie使用模塊化的設計，每個部分都可以自定義然后替換，
擴展電影類型
目前內置了6種類型,后兩種即是抖音的左右切換和上下切換，Thaw和WINDOW仿自美拍
public enum PhotoMovieType { THAW, //融雪 SCALE, //縮放 SCALE_TRANS, //縮放 & 平移 WINDOW, //窗扉 HORIZONTAL_TRANS,//橫向平移 VERTICAL_TRANS//縱向平移 }這里以微視的漸變特效為例展示如何擴展
分析得出，漸變特效首先圖片居中放置，然后全程做一個微弱的放大動畫，后半部分同時透明度變化消失
可見需要兩個不同的片段類型
首先創建FitCenterScaleSegment,繼承FitCenterSegment，實現單張圖片的放大動畫
public class FitCenterScaleSegment extends FitCenterSegment { /** * 縮放動畫范圍 */ private float mScaleFrom; private float mScaleTo; private float mProgress; /** * @param duration 片段時長 * @param scaleFrom 縮放范圍 * @param scaleTo 縮放范圍 */ public FitCenterScaleSegment(int duration, float scaleFrom, float scaleTo) { super(duration); mScaleFrom = scaleFrom; mScaleTo = scaleTo; } @Override protected void onDataPrepared() { super.onDataPrepared(); } @Override public void drawFrame(GLESCanvas canvas, float segmentProgress) { mProgress = segmentProgress; if (!mDataPrepared) { return; } drawBackground(canvas); float scale = mScaleFrom + (mScaleTo - mScaleFrom) * mProgress; //FitCenterSegment已經具有縮放能力，這里傳縮放值即可 drawContent(canvas, scale); } //提升這兩個函數的訪問權限，供轉場時使用 @Override public void drawContent(GLESCanvas canvas, float scale) { super.drawContent(canvas, scale); } @Override public void drawBackground(GLESCanvas canvas) { super.drawBackground(canvas); }}然后創建轉場片段GradientTransferSegment,其父類TransitionSegment同時持有上一個與下一個片段，可以在其基礎上實現任意轉場功能
public class GradientTransferSegment extends TransitionSegment<FitCenterScaleSegment, FitCenterScaleSegment> { /** * 縮放動畫范圍 */ private float mPreScaleFrom; private float mPreScaleTo; private float mNextScaleFrom; private float mNextScaleTo; public GradientTransferSegment(int duration, float preScaleFrom, float preScaleTo, float nextScaleFrom, float nextScaleTo) { mPreScaleFrom = preScaleFrom; mPreScaleTo = preScaleTo; mNextScaleFrom = nextScaleFrom; mNextScaleTo = nextScaleTo; setDuration(duration); } @Override protected void onDataPrepared() { } @Override public void drawFrame(GLESCanvas canvas, float segmentProgress) { //下一個片段開始放大 float nextScale = mNextScaleFrom + (mNextScaleTo - mNextScaleFrom) * segmentProgress; mNextSegment.drawContent(canvas, nextScale); //上一個片段繼續放大同時變透明 float preScale = mPreScaleFrom + (mPreScaleTo - mPreScaleFrom) * segmentProgress; float alpha = 1 - segmentProgress; mPreSegment.drawBackground(canvas); canvas.save(); canvas.setAlpha(alpha); mPreSegment.drawContent(canvas, preScale); canvas.restore(); }創建照片電影
private static PhotoMovie initGradientPhotoMovie(PhotoSource photoSource) { List<MovieSegment> segmentList = new ArrayList<>(photoSource.size()); for (int i = 0; i < photoSource.size(); i++) { if (i == 0) { segmentList.add(new FitCenterScaleSegment(1600, 1f, 1.1f)); } else { segmentList.add(new FitCenterScaleSegment(1600, 1.05f, 1.1f)); } if (i < photoSource.size() - 1) { segmentList.add(new GradientTransferSegment(800, 1.1f, 1.15f, 1.0f, 1.05f)); } } return new PhotoMovie(photoSource, segmentList); }然后將這個PhotoMovie正常播放即可，效果如下
擴展濾鏡
目前內置了9個濾鏡
public enum FilterType { NONE, CAMEO,//浮雕 GRAY,//黑白 KUWAHARA,//水彩 SNOW,//飄雪（動態） LUT1, LUT2, LUT3, LUT4, LUT5,}先看IMovieFilter
public interface IMovieFilter { void doFilter(PhotoMovie photoMovie,int elapsedTime, FboTexture inputTexture, FboTexture outputTexture); void release();}外部會提供一個輸入紋理，然后由IMovieFilter處理之后繪制到輸出紋理上，即實現了濾鏡效果
BaseMovieFilter已經實現了基本的輸入輸出流程，例如要做最基本的黑白濾鏡，只需更換FRAGMENT_SHADER即可
public class GrayMovieFilter extends BaseMovieFilter { protected static final String FRAGMENT_SHADER = "" + "varying highp vec2 textureCoordinate;/n" + " /n" + "uniform sampler2D inputImageTexture;/n" + " /n" + "void main()/n" + "{/n" + " mediump vec4 color = texture2D(inputImageTexture, textureCoordinate);/n" + " mediump float gray = color.r*0.3+color.g*0.59+color.b*0.11;/n"+ " gl_FragColor = vec4(gray,gray,gray,1.0);/n"+ "}"; public GrayMovieFilter(){ super(VERTEX_SHADER,FRAGMENT_SHADER); }}同時PhotoMovie提供了對Lut濾鏡的支持
Lut其實就是Lookup Table（顏色查找表），根據原圖的RGB值去相應的lut圖里面查找對應轉換后的RGB值，從而實現各種濾鏡效果
lut(原圖)
原圖
濾鏡效果圖
public class LutMovieFilter extends TwoTextureMovieFilter { public LutMovieFilter(Bitmap lutBitmap){ super(loadShaderFromAssets("shader/two_vertex.glsl"),loadShaderFromAssets("shader/lut.glsl")); setBitmap(lutBitmap); }}在LutMovieFilter的構造函數傳入上面表格里的lut圖，即可實現相應的濾鏡效果,前面提到的黑白濾鏡也可用這個方式實現
錄制功能
GLMovieRecorder 提供了將照片電影錄制為mp4的功能
可參照 DemoPresenter 的saveVideo()函數
GLMovieRecorder recorder = new GLMovieRecorder(); recorder.configOutput(width, height(), bitrate,frameRate,iFrameInterval, outputPath); recorder.setDataSource(movieRenderer); recorder.startRecord(new GLMovieRecorder.OnRecordListener() { @Override public void onRecordFinish(boolean success) { ...... } @Override public void onRecordProgress(int recordedDuration, int totalDuration) { ...... } });背景音樂
mPhotoMoviePlayer.setMusic(context, mMusicUri);
PhotoMovie只提供了播放背景音樂的功能，錄制完成之后需自行合成，Demo里使用了
VideoProcessor 進行合成
VideoProcessor.mixAudioTrack(context, videPath, audioPath,outputPath, null, null, 0,100, 1f, 1f);
以上就是本文的全部內容，希望對大家的學習有所幫助，也希望大家多多支持VEVB武林網。
