public void createpartcontrol(composite parent) { toolkit = new formtoolkit(parent.getdisplay()); form = toolkit.createform(parent); form.settext("hello, eclipse forms"); gridlayout layout = new gridlayout(); form.getbody().setlayout(layout); hyperlink link = toolkit.createhyperlink(form.getbody(), "click here.", swt.wrap); link.addhyperlinklistener(new hyperlinkadapter() { public void linkactivated(hyperlinkevent e) { system.out.println("link activated!"); } }); } form的body是標題下面的可用空間，因為這個空間是一個swt composite，它能做為其它組件的parent。在上面的代碼里，我們?yōu)閎ody設置了layout，然后創建了一個超鏈接。超鏈接是由eclipse forms提供的為數不多的組件之一，我們可以為超鏈接增加監聽器，這樣能夠在用戶點擊它時做出反應。
layout.numcolumns = 2; griddata gd = new griddata(); gd.horizontalspan = 2; link.setlayoutdata(gd); label label = new label(form.getbody(), swt.null); label.settext("text field label:"); text text = new text(form.getbody(), swt.border); text.setlayoutdata(new griddata(griddata.fill_horizontal)); button button = new button(form.getbody(), swt.check); button.settext("an example of a checkbox in a form"); gd = new griddata(); gd.horizontalspan = 2; button.setlayoutdata(gd); 現在我們使用了兩列,并且創建了一個標簽,一個文本框(text field)和一個復選框(checkbox).結果如下：
label label = toolkit.createlabel(form.getbody(), "text field label:"); text text = toolkit.createtext(form.getbody(), ""); text.setlayoutdata(new griddata(griddata.fill_horizontal)); button button = toolkit.createbutton(form.getbody(), "a checkbox in a form", swt.check); gd = new griddata(); gd.horizontalspan = 2; button.setlayoutdata(gd);這個視圖現在會看來更好些了：
control mycontrol = new mycontrol(parent); mycontrol.setdata(formtoolkit.key_draw_border, formtoolkit.text_border); // or mycontrol.setdata(formtoolkit.key_draw_border, formtoolkit.tree_border); toolkit.paintbordersfor(parent);你可以在上面這張圖中看出,象樹和表格這樣的"結構化(structural)"的組件有和文本區域不同的邊框風格并且你可以選擇和你的組件相符合的那個.注意用toolkit的工廠方法創建出的組件不需要這樣做.
public void createpartcontrol(composite parent) { toolkit = new formtoolkit(parent.getdisplay()); form = toolkit.createform(parent); form.settext("hello, eclipse forms"); tablewraplayout layout = new tablewraplayout(); form.getbody().setlayout(layout); hyperlink link = toolkit.createhyperlink(form.getbody(),"click here.", swt.wrap); link.addhyperlinklistener(new hyperlinkadapter() { public void linkactivated(hyperlinkevent e) { system.out.println("link activated!"); } }); link.settext("this is an example of a form that is much longer and will need to wrap."); layout.numcolumns = 2; tablewrapdata td = new tablewrapdata(); td.colspan = 2; link.setlayoutdata(td); label label = toolkit.createlabel(form.getbody(), "text field label:"); text text = toolkit.createtext(form.getbody(), ""); td = new tablewrapdata(tablewrapdata.fill_grab); text.setlayoutdata(td); button button = toolkit.createbutton(form.getbody(), "a checkbox in a form", swt.check); td = new tablewrapdata(); td.colspan = 2; button.setlayoutdata(td); }我們用了griddata相同的概念.一些變量擁有不同的名字(舉個例子,colspan和rowspan,align和valign取自html table的屬性),但是你可以做相同的事--創建一個超鏈接和按鈕占據兩列的格子.因為空白(margins)和gridlayout是相同的,結果會看起來一樣,除了超鏈接現在會包裹起來：
tablewraplayout和gridlayout的一個主要的不同點是你應該停止去計算垂直的空間.在gridlayout里,你一般會讓"不易變形的"組件用自然的位置和大小并讓"可伸縮的(flexible)"組件去占據水平或垂直的空間.相反,tablewraplayout是從上往下工作的,并且它容下所有的組件,它的工作是完全的.占據水平空間的概念還存在(象上面展示一樣).但是,垂直方向上,你只能在單元比組件高時選擇fill單元,或選擇top,middle或bottom垂直對齊.
圖片8：一個使用tablewraplayout的form
layout.numcolumns = 3; label label; tablewrapdata td; label = toolkit.createlabel(form.getbody(), "some text to put in the first column", swt.wrap); label = toolkit.createlabel(form.getbody(), "some text to put in the second column and make it a bit "+ "longer so that we can see what happens with column "+ distribution. this text must be the longest so that it can "+ "get more space allocated to the columns it belongs to.", swt.wrap); td = new tablewrapdata(); td.colspan = 2; label.setlayoutdata(td); label = toolkit.createlabel(form.getbody(), "this text will span two rows and should not grow the column.", swt.wrap); td = new tablewrapdata(); td.rowspan = 2; label.setlayoutdata(td); label = toolkit.createlabel(form.getbody(), "this text goes into column 2 and consumes only one cell", swt.wrap); label.setlayoutdata(new tablewrapdata(tablewrapdata.fill_grab)); label = toolkit.createlabel(form.getbody(), "this text goes into column 3 and consumes only one cell too", swt.wrap); label.setlayoutdata(new tablewrapdata(tablewrapdata.fill)); label = toolkit.createlabel(form.getbody(), "this text goes into column 2 and consumes only one cell", swt.wrap); label.setlayoutdata(new tablewrapdata(tablewrapdata.fill_grab)); label = toolkit.createlabel(form.getbody(), "this text goes into column 3 and consumes only one cell too", swt.wrap); label.setlayoutdata(new tablewrapdata(tablewrapdata.fill)); form.getbody().setbackground(form.getbody().getdisplay(). getsystemcolor(swt.color_widget_background));
這個創建了一些有不同長度文本的label.有些labels占據多列,有些占據多行.為了讓測試更加簡單，我們把form的背景設置為組件背景,這樣單元能夠更簡單看出來.當我們運行例子,我們會得到下面的樣子：
關鍵之處在于組件最小寬度和最大寬度相比較時.相差越多,結果越明顯,會看到列中有很大的縫隙.占據的寬度是組件所需要的最小的寬度.注意第3列比第2列稍微寬一點點,這是因為第3列中的文字長度比第2列中文字要長點.如果需要閱讀布局的相關理論,可以去這里w3c recommendations for html table auto-layout.
圖片9：tablewraplayout留下的多余空間
